The amplifier has unique and patented technologies that make the sound experience cleaner and more faithful, besides ensuring better performance and efficiency for the most daring projects.
General SpecificationsGeneral Specifications
+
1600.1 EVO 5 – 1 OHM
Power @ 1Ω: 1 X 1600 WRMSPower @ 2Ω: 1 X 1056 WRMSPower @ 4Ω: 1 X 697 WRMS
1600.1 EVO 5 – 2 OHMS
Power @ 1Ω: N/APower @ 2Ω: 1 X 1600 WRMSPower @ 4Ω: 1 X 1056 WRMS
1600.1 EVO 5 – 4 OHMS
Power @ 1Ω: N/APower @ 2Ω: N/APower @ 4Ω: 1600 WRMS
Response Frequency (-3dB):
5Hz ~ 25kHz
Subsonic Filter:5Hz ~ 80Hz
Low Pass Filter:
50Hz ~ 1kHz
Graves Reinforcement:
0dB ~ 12dB @ 50Hz
Power Voltage:
9V ~16V
Signal-To-Noise Ratio:
1Ω: 93.7dB2Ω: 95dB4Ω: 93.4dB
Input Sensitivity:
0.2V ~2V
Music Consumption:
1Ω: 75A2Ω: 71A4Ω: 69.4A
With Resistive Load:
1Ω: 149A2Ω: 143A4Ω: 138.8A
Total Efficiency:
1Ω: 85%2Ω: 89%4Ω: 91.5%
Damping Factor:
>2000
Power Cord:16mm² (5 AWG)
Audio Output Cable:
2 x 1.5 mm² (15 AWG)
Recommended Fuse (Musical):
80A
Recommended Battery (Minimum for Music Use):
80ah
Width:
13.6 cm
Length:
18 cm
Height:
5.48 cm
Weight:
1.13 kg
