High quality 4 Way 120 x 180 mm / 6”x9”coaxial speaker with HQPP-Cone
Resonance free steel basket – Rubber surround – 0.51” Mylar-tweeter with overload protection
Mounting diameter of midwoofer or midrange 150 x 223 mm / 6”x8.88”
Mounting depth of midwoofer or midrange 83 mm / 3.27″
Voice coil of midwoofer or midrange 25 mm / 1″ Cone of midwoofer or midrange HQPP Dustcap
Voice coil of tweeter 55 mm / 2.17” & 2 x18 mm / 0.71”
Cone of tweeter Mylar Housing of tweeter Plastic injection Magnet of tweeter Ferrit and Piezoelectric
Power handling WRMS 120 W Power handling W peak 180 W
Impedance 4 Ohm SPL 92 dB Frequency response 40 HZ – 20 kHz
